MSI PRO Z890-P WiFi DDR5 Motherboard LGA 1851 - Technical Specifications
| Brand | MSI |
| Model | PRO Z890-P WiFi |
| Chipset | INTEL Z890 |
| CPU |
Supports Intel® Core™ Ultra Processors (Series 2) LGA 1851 |
| Memory |
4x DDR5 UDIMM, Maximum Memory Capacity 256GB Supports Intel® POR Speed and JEDEC Speed |
| Onboard Graphics |
1x HDMI™ Support HDMI™ 2.1, maximum resolution of 4K 60Hz* 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz* 1x Type-C DisplayPort Thunderbolt™ 4 port, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz* |
| Slot |
3x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) PCI_E4 Gen PCIe 4.0 supports up to x4 (From Chipset) |
| Audio |
Realtek® ALC897 Codec 7.1-Channel High Definition Audio |
| Storage |
4x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G |
| USB |
4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 5Gbps Type A (Rear) 4x USB 5Gbps Type A (Front) 1x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Rear) 1x USB 20Gbps Type C (Front) |
| LAN | Realtek® 8126 5Gbps LAN |
| Internal IO |
1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 5x System Fan 1x EZ Conn-header (JAF_1) 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 4x USB 5Gbps Type A ports 1x USB 20Gbps Type C ports |
| LED FEATURE | 4x EZ Debug LED |
Next-Generation Foundation: MSI PRO Z890-P WiFi Motherboard 🖥️
The MSI PRO Z890-P WiFi DDR5 is the essential backbone for building a high-performance, future-ready professional or gaming desktop. Designed for maximum reliability and cutting-edge features, this ATX motherboard seamlessly integrates with the latest components.
This motherboard is built around the advanced Intel Z890 chipset and features the LGA 1851 socket, ensuring support for the next generation of Intel Core processors. It leverages the speed of high-frequency DDR5 RAM, delivering unprecedented memory performance for demanding multitasking and complex applications.
The PRO Z890-P is a master of connectivity, including a primary PCIe 5.0 x16 slot ready for the fastest new graphics cards and multiple M.2 slots for lightning-fast PCIe 5.0 and 4.0 NVMe SSDs. Networking is superb with integrated Wi-Fi 7 for ultra-low latency wireless speeds and a high-speed 2.5G LAN port.
MSI's robust power design and optimized cooling solutions ensure peak component stability, essential for professionals and creators running intensive applications. Choose the MSI PRO Z890-P WiFi for a dependable, high-bandwidth, and future-proof desktop platform.
Key Features:
- Chipset: Intel Z890
- Socket: LGA 1851 (Next-Gen Intel CPU Support)
- Memory: DDR5 Support
- Expansion: PCIe 5.0 x16 Slot, Multiple M.2 Slots
- Networking: Integrated Wi-Fi 7 and 2.5G LAN
- Form Factor: ATX
Build the next generation—shop the MSI PRO Z890-P WiFi motherboard today!
